1.6 Radio Digital 60mhz Meter Swr - 2017a Mobile Redot Am/fm/ssb/cw Worth Quincy Rating: 3.5 out of 5
Inexpensive cost and free shipping. Allow's buy prior to prices climb.
Economical price as well as cost-free shipping. Let's get before costs increase.
This Limited 1.6 Radio Digital 60mhz Meter Swr - 2017a Mobile Redot Am/fm/ssb/cw product is really special, made with high quality materials definitely sturdy for use in a lengthy period. Prior to you use it, ensure you review the overview carefully. Do not make a blunder when utilizing it. When utilizing it, quality products ensure your life more comfy. You could directly call the sales to get even more info concerning this top quality goods if you are interested to get it.
REDOT 2017A Mini Digital Power SWR Meter 199W AM/FM/SSB/CW 1.6 - 60MHz for 2-way radio mobile radio Digital swr meter
Features:
u Battery installation: Remove 4 black round screws on the corner of back cover and open it. Install 3 AAA batteries. BE CAUTIOUS to the polarities. Put the cover on and fasten the screws. IMPROPER INSTALLATION OF BACK COVER WILL CAUSE ERROR ON U-BAND MEASUREMENT!
u Connect the Output of your transceiver to "TX" and Antenna or Load to "ANT". NOTE: UHF connectors (normally named "M", SL16, SO239 ect.) for HF-Band. Proper adaptor/cable is required if your device has different type of connectors.
u Press the red button to power on. After 2 seconds of LCD self test, its ready for normal measurement.
HF-Band meter will display in sequence:"+ XXX P" (passthrough power),": XXX P" (passthrough power)," XXX " (SWR value), 2 seconds display for each mode. Press the red button will hold the current display. Press it again to continue the display.
u Under the environment of night or weak illumination, just press and hold the red button for 1 second to turn the blue back light on. Press and hold the red button for 1 second again to turn it off.
u 8 minutes after no power was measured, it will power off automatically. Press and hold the red button for 2 seconds to turn off manually.
u This is the quick reference. More detailed information for Digital SWR/Power Meter are available at the following wed sites and forums.
Specification:
| MAX.POWER: | 199W |
| VSWR: | 1.00 ~ 19.9 |
| Frequency Range: | 1.6MHz - 60MHz |
| Display: | 3 1/2 LCD |
| Conversion Resolution: | 100/S,12BIT |
| Insertion loss: | < 0.2 dB |
| Direction: | > 30 dB |
| Battery: | AAA*3 |
| Size: | 67 * 69 * 37 (mm) |
| Interface: | UHF-KF(SO239) |
| Net Weight: | 300g |
Package:
| 1x Digital Power & SWR Meter 1 x User Manual
|
